Product Summary
The MAX7456 single-channel monochrome on-screen
display (OSD) generator lowers system cost by eliminating the need for an external video driver, sync separator, video switch, and EEPROM. The MAX7456 serves
all national and international markets with 256 user-programmable characters in NTSC and PAL standards.
The MAX7456 easily displays information such as company logo, custom graphics, time, and date with arbitrary characters and sizes. The MAX7456 is preloaded
with 256 characters and pictographs and can be reprogrammed in-circuit using the SPI
TM
port.
Features
256 User-Defined Characters or Pictographs in
Integrated EEPROM
? 12 x 18 Pixel Character Size
? Blinking, Inverse, and Background Control
Character Attributes
? Selectable Brightness by Row
? Displays Up to 16 Rows x 30 Characters
? Sag Compensation On Video-Driver Output
? LOS, VSYNC, HSYNC, and Clock Outputs
? Internal Sync Generator
? NTSC and PAL Compatible
? SPI-Compatible Serial Interface
? Delivered with Preprogrammed Character Set
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 MAX7456EUI+ |
Maxim Integrated Products |
Video ICs Monochrome On Scrn Display Generator |
Data Sheet |
|
|
||||||||||||
|
MAX7456EUI+T |
Maxim Integrated Products |
Video ICs Monochrome On Scrn Display Generator |
Data Sheet |
|
|
||||||||||||
